FANUC CNC Setting Tool
OPERATOR’S MANUAL
After this step, continue the installation following the instruction of installer.
When the screen for entering Serial Number is displayed, input the printed
value. The installer distinguishes between a capital letter and a small letter
for a Serial Number.
2.2 UNINSTALLATION
The procedure for uninstalling the CNC setting tool is described below.
1 Choose [Start] then [S
ettings] then [Control Panel] to open the Control
Panel screen.
2 Double-click [Add/Remove Programs] on the Control Panel screen.
The Add/Remove Programs screen is displayed.
3 Select "CNC Setting Tool (NCParam)" from the list on the Add/Remove
Programs screen then click [R
emove].
Previous page
Next page
