FANUC CNC Setting Tool
OPERATOR’S MANUAL
Setting item
Item Description
(List box) Set a save data file to be used for uploading
from the CNC.
Right-click the line displaying a configuration
tool name then choose [Select File]. The
Open File screen is displayed. On the Open
File screen, specify a save location and save
data file name.
Tools Displays a selected configuration tool name.
File
name
Displays a data file name specified on the
Open File screen.
Comm
Setting
Set the FOCAS2/Ethernet parameters to be
used for uploading from the CNC.
The values set on the Machine Property
screen are initially set.
IP
Address
Set an IP address.
Port Set a port number.
Set a time-out period. Timeout
Range: 1 to 65535 (Unit: Second)
Button
Item Description
OK Starts uploading from the CNC.
Upon completion of communication, this
screen is closed, and the file is updated in the
list of files.
Cancel Cancels operations on this screen and closes
this screen.
Previous page
Next page
