FANUC CNC Setting Tool
OPERATOR’S MANUAL
All Parameter List
It is one of the parameter showing method. All parameters are displayed in
order. The parameter number search is available.
Function Setting
It is another parameter showing method. Parameters are displayed in the
classification of the CNC function.
Requirements on the personal computer
The table below indicates the requirements to be satisfied by the personal
computer when the CNC setting tool is used.
Item Requirements
OS Windows XP Professional
Windows 2000 Professional
Windows NT4.0 (Service Pack 6 or later)
HDD size used
110M bytes (when installed)
Drive CD-ROM drive
The CNC setting tool is distributed with a
CD-ROM.
Memory Card drive
It is required if a parameter file is
transmitted via memory card.
NOTE
To install or uninstall the CNC setting tool, the user
needs to have the "Administrator authority".
To operate the CNC setting tool, the user needs to
have the "Administrator authority" or "Power User
authority" when the OS is Windows 2000
Professional or NT4.0, or the user needs to have
the "Administrator authority" when the OS is
Windows XP Professional.
