Fast Ethernet Board/Fast Data Server Operators manual Page 280

Operators manual
6.15i
i i
i DATA SERVER FUNCTIONS IV. OPERATION B-63644EN/02
- 266 -
6.8.2 Outputting Parameters
A file (parameters) is output from the tape memory to the Fast data
server built-in ATA card or host computer built-in hard disk.
To the Parameter screen
Procedure
1 Press function key
SYSTEM
.
2 Press soft key [CHAPTER].
3 When you press soft key [PARAMETER], the Parameter screen
appears.
4 Press the operation menu key at the right end of the soft key
menu.
5 Press soft key [PUNCH].
6 Enter the file name using the MDI keys.
7 Press soft key [PARAMETER].
8 During input, PNCH blinks at the top of the screen.
File formats and restrictions
Refer to the Series 15i-B Operator's manual (B-63784EN).
Output destination
Storage mode : Fast data server built-in ATA card
FTP mode : Host computer built-in hard disk
Buffer mode : Fast data server built-in ATA card
