1.FACTOLINK FUNCTIONS FOR THE 16i/18i/21i III. SETTING B-63644EN/02

- 32 -

No.1 CNC No.2 CNC

IP address 192.168.0.1 192.168.0.2

Subnet mask 255.255.255.0 255.255.255.0

Router IP address None None

IP address 1 192.168.0.101 192.168.0.101

Port No.1 9000 9000

IP address 2 None None

Port No.2 None None

IP address 3 None None

Port No.3 None None

Parameter No.802 11 11

Parameter No.820 67 'C' 67 'C'

Parameter No.821 78 'N' 78 'N'

Parameter No.822 67 'C' 67 'C'

Parameter No.823 49 '1' 50 '2'

No.1 Personal computer

IP address 192.168.0.101

Subnet mask 255.255.255.0

Default gateway None

ocsnc 9000/tcp

ocscomm 9001/tcp

ocsapplication 9002/tcp

Set these items in “Microsoft TCP/IP Property” on

the personal computer (WindowsNT).

See 2.3.2 of the "FACTOLINK Script

Function

OPERATOR'S MANUAL."

Set these items in the

“Ethernet Parameters screen.

Set this item in the

Parameters Screen. See IV
