Fast Ethernet Board/Fast Data Server Operators manual Page 60

Operators manual
3.FOCAS1/Ethernet FUNCTIONS FOR THE 16i/18i/21i/PMi III. SETTING B-63644EN/02
- 46 -
3.1 PRECAUTIONS TO BE OBSERVED WHEN USING THE
FOCAS1/Ethernet FUNCTIONS FOR THE FIRST TIME
CAUTION
When the Fast Ethernet board is used for the first
time, consult with your company’s network
administrator to determine the IP addresses and
other settings. Then, conduct a communications test.
If incorrect IP addresses and other settings are set,
communications may be interfered with or the entire
network might be adversely affected.
Particularly, if a duplicate IP address is set,
communication errors are caused intermittently. This
may result in a CNC's system error. To check
whether the IP address duplicates any one already in
use, see "Checking IP addresses for duplication" in
Appendix A.3, "Checking Communication."
NOTE
1 One of the following option functions is needed when
the FOCAS1/Ethernet functions are used:
Series16i-TA A02B-0236-S707
Series 16i-MA A02B-0237-S707
Series 18i-TA A02B-0238-S707
Series 18i-MA A02B-0239-S707
Series 21i-TA A02B-0247-S707
Series 21i-MA A02B-0248-S707
Power Mate i A02B-0259-J862
Series16i-TB A02B-0281-S707
Series 16i-MB A02B-0282-S707
Series 18i-TB A02B-0283-S707
Series 18i-MB A02B-0284-S707
Series 21i-TB A02B-0285-S707
Series 21i-MB A02B-0286-S707
Series16i/18i/21i-A A02B-0207-J800
Power Mate i A02B-0259-J847
2 Up to twenty FOCAS1/Ethernet clients can be
connected to one CNC by the FOCAS1/Ethernet
functions.
