  2. FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications

FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications Additional Manual Page 10

Additional Manual
Edit
Apprv.
Desig.
Date
Design
Date
FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
10/67
page
Title
Draw
No.
Description
Format
Registration after deletion of all groups
M
Format Meaning
G10L3;
P-L-;
T-H-D-;
T-H-D-;
･
P-L-;
T-H-D-;
T-H-D-;
･
G11;
M02(M30);
G10L3: Register data after deleting data of all groups
P-: Group number
L-: Tool life value
T-: Tool number
H-: Code specifying tool offset value (H code)
D-: Code specifying tool offset value (D code)
G11: End of registration
T
Format Meaning
G10L3;
P-L-;
T-(D-);
T-(D-);
･
P-L-;
T-(D-);
T-(D-);
･
G11;
M02(M30);
G10L3: Register data after deleting data of all groups
P-: Group number
L-: Tool life value
T-: For turret type (bit 3 (TCT) of parameter No. 5040 =
0)
Tool number and tool offset number
For ATC type (bit 3 (TCT) of parameter No. 5040 = 1)
Tool number
G11: End of registration
(D-): For ATC type (bit 3 (TCT) of parameter
No. 5040 =
1)
Code specifying tool offset value
NOTE
Even when the tool change type is the ATC type (bit 3 (TCT) of
parameter No. 5040 = 1), the H code is not used.
