FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications Additional Manual Page 18

Additional Manual
Edit
Apprv.
Desig.
Date
Design
Date
FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
18/67
page
Title
Draw
No.
Description
Selects the H code registered in tool life management data for the currently used tool to
perform tool length offset. An H code other than H99 can also be used to enable
compensation by setting parameter No. 13265.
H00；
Cancels tool length offset.
D99；
Selects the D code registered in tool life management data for the currently used tool to
perform cutter compensation. A D code other than D99 can also be used to enable
compensation by setting parameter No. 13266.
D00；
Cancels cutter compensation.
NOTE
H99 and D99 must be specified after the M06 command. If a code
other than H99 and D99 or a code other than the H and D codes set
in parameter Nos. 13265 and 13266 is specified following M06, the H
code or D code of tool life management data is not selected.
