FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
56/67
page
Title
Draw
No.
Description
1.4 PARAMETERS
#7 #6 #5 #4 #3 #2 #1 #0
6800
M6T IGI SNG GRS SIG LTM GS2 GS1
[Input type] Parameter input
[Data type] Bit path
# 0 GS1
# 1 GS2 For the maximum number of groups set in parameter No. 6813, up to
four tools can be registered per group. The combination of the number
of registerable groups and the number of tools per group can be changed
by setting GS1 and GS2.
GS2 GS1 Number of groups
Number of
tools
0 0 1/8 of maximum number of groups
(No.6813)
32
0 1 1/4 of maximum number of groups
(No.6813)
16
1 0 1/2 of maximum number of groups
(No.6813)
8
1 1 Maximum number of groups
(No.6813)
4
CAUTION
After changing these parameters, set data again by using G10
L3 ;
(registration after deletion of data of all groups)
.
# 2 LTM The tool life count is specified by:
0: Count.
1: Duration.
NOTE
After changing this parameter,set data again by using G10
L3 ;(registration after deletion of data of all groups).
