FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications Additional Manual Page 46

Additional Manual
Edit
Apprv.
Desig.
Date
Design
Date
FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
46/67
page
Title
Draw
No.
Description
NOTE
1 Deleting all tools in a tool group is equivalent to deleting the tool
group.
2 When a tool marked with "@" (being used) is deleted, the mark "@"
shifts to the tool whose life has expired or has been skipped most
recently.
- Skipping a tool
Tool data is skipped.
(1) Select the MDI mode.
(2) Move the cursor to the tool data (T, H, or D code) of the tool to be skipped.
(3) Press the [STATE] soft key.
(4) Press the [SKIP] soft key.
- Clearing the life count (resetting the life)
Tool data is cleared.
(1) Select the MDI mode.
(2) Move the cursor to the tool data (T, H, or D code) of the tool to be cleared.
(3) Press the [STATE] soft key.
(4) Press the [CLEAR] soft key.
- Selecting a tool group
A tool group is selected.
Procedure 1
(1) Type a tool group number.
(2) Press the [NO.SRH] soft key.
NOTE
When the arbitrary group number function is enabled, a tool group is
searched for using an arbitrary group number instead of a tool group
number.
Procedure 2
(1) Press page keys
PAGE
PAGE
to display a target group.
- Changing to the list screen
The screen display returns to the tool life management (list screen).
(1) Press the [END] soft key.
