FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
15/67
page
Title
Draw
No.
Description
Tool life value
- When the life management B function is disabled
When the tool life management B function is disabled (bit 4 (LFB) of parameter No. 6805 =
0), a tool life value is registered as a duration or a use count according to the setting of bit 2
(LTM) of parameter No. 6800 or the setting of a count type (Q command). The maximum
values are listed below.
Table 1.1.2 (a) Life count types and maximum life values
LFB
(No.6805#4 )
LTM
（No.6800#2）
Life count type Maximum life value
0 Use count specification 65535 times
0
1 Duration specification 4300 minutes
When the count type is duration specification, the unit of a life value specified with address
L in a program may be one minute or 0.1 second, which is determined by the setting of bit 1
(FGL) of parameter No. 6805.
Table 1.1.2 (b) Life value unit and maximum value in L command
LFB
(No.6805#4 )
FGL
（No.6805#1）
Life value
unit
Maximum value
in L command
Example
0 1 minute 4300 L100 :
Life value is 100
minutes.
0
1 0.1 second 2580000 L1000 :
Life value is 100
seconds.
