  2. FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications

FANUC Series 30i/31i/32i-MODEL A Tool Life Management Specifications Additional Manual Page 14

Additional Manual
Edit
Apprv.
Desig.
Date
Design
Date
FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
14/67
page
Title
Draw
No.
Description
Remaining life setting
When the tool life management B function is enabled (bit 4 (LFB) of parameter No. 6805 =
1), and a remaining life value is to be set for each group (bit 3 (GRP) of parameter No. 6802
= 1), a remaining life value can be set as tool life management data by programming a
command.
Format Meaning
G10L3;
(or
G10L3P1);
P-L-R-;
T-H-D-;
T-H-D-;
･
G11;
M02(M30);
R-:
Remaining life setting (remaining life until a new tool
is selected)
NOTE
1 If the remaining life setting (R) is 0 or omitted, the value is assumed
to be 0. In this case, the life arrival notice function is disabled.
2 The remaining life setting (R) must not be greater than the life value
(L). If a value greater than the life value is specified, an alarm
(PS0431) is issued.
3 As the remaining life setting (R), an unsigned value having no
decimal point must be specified.
4 The unit of the remaining life setting (R) depends on the setting of bit
1 (FGL) of parameter No. 6805, which selects the unit of the tool life
value.
