FANUC Series 30i/31i/32i−MODEL A
Tool Life Management
Specifications
-
79409E
Sep.10.’04
13/67
page
Title
Draw
No.
Description
Arbitrary group number
M
When the tool life management B function is enabled (bit 4 (LFB) of parameter No. 6805 =
1), and use of the function for specifying an arbitrary group number is set (bit 5 (TGN) of
parameter No. 6802 = 1), an arbitrary group number can be registered by programming a
command.
Format Meaning
G10L3;
(or
G10L3P1);
P-L-T-;
T-H-D-;
T-H-D-;
･
G11;
M02(M30);
T-: Arbitrary group number (1 to 99999999)
NOTE
1 A group number that is the same as the group number of another
group cannot be registered.
An attempt to register such a group number results in an alarm
(PS0431).
2 If an arbitrary group number (T) is 0, an alarm (PS0431) is issued.
3 Whenever an arbitrary group number is specified, the T command
must be specified. If the T command is omitted, an alarm (PS0149)
is issued.
T
The function for specifying an arbitrary group number is available only when the tool change
type is the ATC type (bit 3 (TCT) of parameter No. 5040 = 1).
When the tool change type is the ATC type, the format used for setting an arbitrary group
number is the same as for the M series.
