Series 0i/0i Mate - Model B Maintenance manual Page 199

Maintenance manual

Page of 719

/ 719

B–63835EN/03

2. HARDWARE

175

Type Item Drawing No. Remarks

0i Mate–B Basic unit with 1 slot A02B–0301–B801

0i–B Basic unit with 2 slots A02B–0299–B802

Type Item Drawing No. ID Remarks

Master Main CPU board

A16B–3200–0490 0X06 0i–B (for PMC–SA1)

PCB

A16B–3200–0491 1X06 0i–B (for PMC–SB7)

A16B–3200–0495 1X07 0i Mate–B

Card PCB CPU card DRAM 16MB 486 A20B–3300–0293 CPU: 09

DRAM: 89

DRAM 32MB 486 A20B–3300–0292 CPU: 09

DRAM: 84

0i–B only

DRAM 32MB Pentium A20B–3300–0319 CPU: 11

DRAM: 84

0i–B only

Card PCB Display control card

LCD/MDI A20B–3300–0341 –

CRT/MDI A20B–3300–0410 –

MDI only A20B–3300–0363 –

Axis control card

2 axes A20B–3300–0033 00

Servo software

4 axes A20B–3300–0032 01

Series 9096

2 axes A20B–3300–0243 08

Servo software

4 axes A20B–3300–0242 08

Series 90B0

Display control card

10.4″ color/8.4″ color A20B–3300–0280 – Graphic

(LCD unit side)

7.2″ monochrome A20B–3300–0283 – Graphic

7.2″ monochrome A20B–3300–0303 – Character only

Power

supply unit

Power supply unit A02B–8100–0721 –

2.5

UNITS AND PRINTED

CIRCUIT BOARDS

2.5.1

Basic Units

2.5.2

Printed Circuit Boards

of Control Unit
