B–63835EN/03

6. DIGITAL SERVO

395

(2)Motor ID No.

Select the motor ID No. of the servo motor to be used, according to the

motor model and drawing number (the middle four digits of

A06B–XXXX

–BXXX) listed in the tables on subsequent pages.

For motors that are not described in this manual, refer to the parameter

manual for servo motors.

NOTE

Servo axes are controlled in groups of two axes. So, for

successive servo control numbers (odd number and even

number), motor type number unified for servo HRV1 or for

servo HRV2 or HRV3 must be specified.

(a) αi series servo motor

In the following tables for αi series servo motor, The motor type

numbers not enclosed in parentheses are for servo HRV1, and the

motor type numbers enclosed in parentheses are for servo HRV2

and HRV3.

- αi series servo motor (Series 0i–B only)

Motor model α1/5000i α2/5000i α4/3000i α8/3000i

Motor specification 0202 0205 0223 0227

Motor type No. 152(252) 155(255) 173(273) 177(377)

Motor model α12/3000i α22/3000i α30/3000i α40/3000i

Motor specification 0243 0247 0253 0257

Motor type No. 193(293) 197(297) 203(303) 207(307)

- αCi series servo motor

Motor model αC4/3000i αC8/2000i αC12/2000i αC22/2000i

Motor specification 0221 0226 0241 0246

Motor type No. 171(271) 176(276) 191(291) 196(296)

Motor model αC30/1500i

Motor specification 0251

Motor type No. 201(301)
