Series 0i/0i Mate - Model B Maintenance manual Page 99

Maintenance manual

Page of 719

/ 719

B–63835EN/03

1. DISPLAY AND OPERATION

450 Spindle position error during rigid tapping

DGN

[Data type] Word

[Unit of data] Detection units

451 Spindle distribution during rigid tapping

DGN

[Data type] Word

[Unit of data] Detection units

454 Accumulated spindle distribution during rigid tapping

DGN

[Data type] Two–word

[Unit of data] Detection units

455 Instantaneous difference for the move command, calculated in terms of the spindle,

during rigid tapping (signed, accumulated value)

DGN

[Data type] Two–word

[Unit of data] Detection units

456 Instantaneous difference for the travel error, calculated in terms of the spindle,

during rigid tapping (signed)

DGN

[Data type] Word

[Unit of data] Detection units

457 Width of synchronization error during rigid tapping (maximum value)

DGN

[Data type] Word

[Unit of data] Detection units

510

#6 #5 #4 #3 #2 #1 #0

DGN

This data indicates the internal Open CNC information (not available to

general users).

511

#6 #5 #4 #3 #2 #1 #0

DGN

This data indicates the internal Open CNC information (not available to

general users).

D Diagnostic data related

to rigid tapping

D Open CNC
