Series 0i/0i Mate - Model B Maintenance manual Page 221

Maintenance manual

Page of 719

/ 719

B–63835EN/03

2. HARDWARE

197

Part programs, offset data, and system parameters are stored in CMOS

memory in the control unit. The power to the CMOS memory is backed

up by a lithium battery mounted on the front panel of the control unit. The

above data is not lost even when the main battery goes dead. The backup

battery is mounted on the control unit at shipping. This battery can

maintain the contents of memory for about a year.

When the voltage of the battery becomes low, alarm message “BAT”

blinks on the CNC display and the battery alarm signal is output to the

PMC. When this alarm is displayed, replace the battery as soon as

possible. In general, the battery can be replaced within two or three

weeks, however, this depends on the system configuration.

If the voltage of the battery becomes any lower, memory can no longer

be backed up. Turning on the power to the control unit in this state causes

system alarm 935 (ECC error) to occur because the contents of memory

are lost. Clear the entire memory and reenter data after replacing the

battery.The power to the control unit must be turned on when the battery

is replaced. If the battery is disconnected when the power is turned off,

the contents of memory are lost.

Observe the following precautions for lithium batteries:

WARNING

If an unspecified battery is used, it may explode.

Replace the battery only with the specified battery

(A02B–0200–K102.)

Dispose of batteries used in accordance with the applicable laws of your

country or the applicable laws or regulations of your local self–governing

body. Before disposal, insulate the terminals with tape or something

similar to prevent them from being short–circuited.

1 Use a litium battery (ordering drawing number :

A02B–0200–K102)

2 Turn on the Series 0i/0i Mate for about 30 seconds and then turn it off

again.

3 Turn off the Series 0i/0i Mate.

2.11

REPLACING THE

BATTERY

2.11.1

Battery for Memory

Backup (3VDC)

Replacing the battery
