4.INTERFACE BETWEEN CNC AND PMC

361

Symbol M seriesT seriesAddress Signal name

TMRON General-purpose integrating meter start signal G053#0 f f

TRQL1 to TRQL4 Torque limit reached signal F114 f –

UI000 to UI015 Input signal for custom macro G054,G055 f f

UINT Interrupt signal for custom macro G053#3 f f

UO000 to UO015 F054,F055 f f

UO100 to UO131

Output signal for custom macro

F056 to F059 f f

WOQSM

Workpiece coordinate system shift value write mode select

signal

G039#6 f –

WOSET Workpiece coordinate system shift value write signal G040#7 f –

XAE X004#0 f f

YAE X004#1 – f

ZAE

Measuring position reached signal

X004#1 f –

ZAE X004#2 – f

ZP1 to ZP4 Reference position return end signal F094 f f

ZP21 to ZP24 2nd reference position return end signal F096 f f

ZP31 to ZP34 3rd reference position return end signal F098 f f

ZP41 to ZP44 4th reference position return end signal F100 f f

ZRF1 to ZRF4 Reference position establishmentsignal F120 f f

ZRN Manual reference position return selection signal G043#7 f f

ZRNO Software operator's panel signal(ZRN) F073#4 f f
