B–63835EN/03

4.INTERFACE BETWEEN CNC AND PMC

353

Symbol M seriesT seriesAddress Signal name

ENB F001#4 f f

ENB2 Spindle enable signal F038#2 f –

ENB3 F038#3 f –

ENBKY External key input mode selection signal G066#1 f f

EOTNA F130#6 f f

EOTNB

F133#6 f f

EOTNC

Negative-direction overtravel signal (PMC axis control)

F136#6 f f

EOTND F139#6 f f

EOTPA F130#5 f f

EOTPB

F133#5 f f

EOTPC

Positive-directionovertravel signal (PMC axis control)

F136#5 f f

EOTPD F139#5 f f

EOV0 Override 0% signal (PMC axis control) F129#5 f f

EPARM Slave parameter selection signal F177#6 f f

EPN0 to EPN13 Expanded workpiece number search signals G024#0 to G025#5 f f

EPNS Expanded workpiece number search start signal G025#7 f f

EPRG Slave program selection signal F177#4 f f

ERDIO Slave external read start signal F177#1 f f

EREND Read completionsignal for external data input F060#0 f f

ERS External reset signal G008#7 f f

ESBKA G142#3 f f

ESBKB G154#3 f f

ESBKC

Block stop signal (PMC axis control)

G166#3 f f

ESBKD G178#3 f f

ESEND Search completionsignal for external data input F060#1 f f

ESKIP Skip signal (PMC axis control) X004#6 f f

ESOFA G142#4 f f

ESOFB G154#4 f f

ESOFC

Servo off signal (PMC axis control)

G166#4 f f

ESOFD G178#4 f f

ESTB Read signal for external data input G002#7 f f

ESCAN Search cancel signal for external data input F060#2 f f

ESTPA G142#5 f f

ESTPB G154#5 f f

ESTPC

Axis control temporary stop signal (PMC axis control)

G166#5 f f

ESTPD G178#5 f f

ESTPIO Slave read/write stop signal F177#2 f f

EVAR Slave macro variable selection signal F177#5 f f

EWTIO Slave external write start signal F177#3 f f

EXLM Stored stroke limit select signal G007#6 f f
