B–63835EN/03

4.INTERFACE BETWEEN CNC AND PMC

289

Input format Module name

(Actual module name)

AC output OA05E

(AOA05E)

OA08E

(AOA08E)

OA12E

(AOA12E)

Relay output OA08G

(AOA08G)

OA16G

(AOA16G)

Name Module name Occupied

address

FANUC CNC SYSTEM

FANUC Power Mate

FS04A Input 4 bytes

Output 4 bytes

FS08A Input 8 bytes

Output 8 bytes

OC02I Input 16 bytes

OC02O Output 16 bytes

OC03I Input 32 bytes

OC03O Output 32 bytes

Analog input module AD04A

(AAD04A)

Input 8 bytes

Analog output module DA02A

(ADA02A)

Output 4 bytes

Connection unit (1 unit) CN01I Input 12 bytes

Connection unit (1 unit) CN01O Output 8 bytes

Connection unit (2 units) CN02I Input 24 bytes

Connection unit (2 units) CN02O Output 16 bytes

Operator’s panel connection unit OC01I Input 12 bytes

I/O card E

OC01O Output 8 bytes

Operator’s panel connection unit /8 Input 8 bytes

I/O card D

/4 Output 4 bytes

Machine operator’s panel interface unit OC02I Input 16 bytes

OC02O Output 16 bytes

OC03I Input 32 bytes

OC03O Output 32 bytes

I/O Link connection unit /j Input j bytes

Output j bytes

OC02I Input 16 bytes

OC02O Output 16 bytes

OC03I Input 32 bytes

OC03O Output 32 bytes

For I/O Unit MODEL B #j Input j bytes

Output j bytes

## Input 4 bytes
