5.I/O SIGNALS B-63494EN/02
- 94 -
5.3.6 Caution (Common)
CAUTION
1 The shaded signals are dual signals. (An italic
signal is monitored in dual mode only when the
safety function that uses the signal is enabled.)
2 Emergency stop signals (*ESP) via the PMC
<X008#4> (<X000#7> for loader control) and via
the FSSB <DI+000#0> are checked each other
(dual-check for safety input signals), but *ESP via
the PMC <G008#4> is not checked.
3 *ESP1 (<X008#4> or <X000#7> for loader control)
is directly checked by the CNC. All signals via the
FSSB are directly processed by the monitor CPU.
None of the signals is processed by the PMC.
4 The signals usable only with the FSSB I/O basic
module are 32 input points/24 output points,
namely, DI+000 to 003/DO+000 to 002.
When a safety function that requires the signals
DI+004 to 007/DO+003 to 005 is to be used, an
FSSB I/O extension module is needed.
