Dual Check Safety Operators manual Page 51

Operators manual
B-63494EN/02 4.INSTALLATION
- 45 -
4 INSTALLATION
Except FSSB I/O module, the hardware installation such as field
wiring, power supply, etc. should be referred to connection manual
(B-63003EN) for CNC units and (B-65162E) for servo amplifier.
EMC problem should be referred to EMC guideline manual
(A-72937/E).
Degree of IP protection:
Servo Motors: IP55
Spindle Motors: IP54 with oil-seal, IP40 without oil-seal
Servo and Spindle amplifiers: IP1x
CNC and other accessories: Ipxx
NOTE
Servo/Spindle amplifiers, CNC are to be installed in
IP54 protected cabinets.
The peripheral units and the control unit have been designed on the
assumption that they are housed in closed cabinets.
Environmental conditions for CNC units
Condition LCD–mounted
type control
unit and
display unit
(except unit
with data
server function)
Stand–alone
type control
unit
LCD–mounted
type control
unit with PC
and data server
functions
Operating 0°C to 58°C 0°C to 55°C 5°C to 53°C
Ambient
Temperature
of the unit
Storage
Transport
–20°C to 60°C
Normal 75% RH or less, no condensation 10% to 75% RH,
no condensation
Humidity
Short period(less
than 1 month)
95% RH or less, no condensation 10% to 90% RH,
no condensation
Operating 0.5 G or less
Vibration
Non–operating 1.0 G or less
Operating Up to 1000 m Up to 1000 m
Meters above
sea level
Non–operating Up to 12000 m Up to 12000 m
Environment
Normal machine shop environment (The environment must be
considered if the cabinets are in a location where the density of dust,
coolant, and/or organic solvent is relatively high.)
