Dual Check Safety Operators manual Page 191

Operators manual
B-63494EN/02 11.APPLYCATION OF OTHER FUNCTIONS
- 185 -
1426 External deceleration rate setting 1 in cutting feed
1440 External deceleration rate setting 2 in cutting feed
1443 External deceleration rate setting 3 in cutting feed
[Data type] Word
[Unit of data]
[Valid data range]
Valid data range Increment
system
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Set external deceleration rate for cutting feed.
1427 External deceleration rate setting 1 for each axis in rapid traverse
1441 External deceleration rate setting 2 for each axis in rapid traverse
1444 External deceleration rate setting 3 for each axis in rapid traverse
[Data type] Word axis
[Unit of data]
[Valid data range]
Valid data range Increment
system
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set external deceleration rate for each axis in rapid traverse.
1434 Maximum manual handle feedrate setting 1 for each axis
1442 Maximum manual handle feedrate setting 2 for each axis
1445 Maximum manual handle feedrate setting 3 for each axis
[Data type] Word axis
[Unit of data]
[Valid data range]
Valid data range Increment
system
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set a maximum manual handle feedrate for each axis.
