Dual Check Safety Operators manual Page 199

Operators manual
B-63494EN/02 11.APPLYCATION OF OTHER FUNCTIONS
- 193 -
11.4.3 Signals
11.4.3.1 Details on signals
Spindle stop complete signal
SPSTP <G028#6>
[Classification] Input signal
[Function] The CNC checks that this signal is 1 and then performs orientation
before spindle positioning or spindle positioning.
Spindle unclamp signal
SUCLP <F038#1>
[Classification] Output signal
[Function] This signal specifies that spindle mechanical clamping be released in a
spindle positioning sequence.
When the signal is output, release spindle clamping on the machine
side (release the brake or draw the pin).
[Output condition] For details, refer to the sequence (time chart) in the Connection
Manual (Function).
Spindle unclamp completion signal
*SUCPF <G028#4>
[Classification] Input signal
[Function] This signal indicates that unclamping the spindle is complete in
response to the spindle unclamp signal SUCLP.
Spindle clamp signal
SCLP <F038#0>
[Classification] Output signal
[Function] This signal specifies that the spindle be clamped mechanically in a
spindle positioning sequence.
When the signal is output, perform spindle clamping on the machine
side (insert the brake or pin).
[Output condition] For details, refer to the sequence (time chart) in the Connection
Manual (Function).
Spindle clamp completion signal
*SCPF <G028#5>
[Classification] Input signal
[Function] This signal indicates that clamping the spindle is complete in response
to the spindle clamp signal SCLP.
Spindle orientation completion signal
ZPx <F094>
[Classification] Output signal
[Function] This signal indicates that spindle orientation of the spindle positioning
is completed.
[Output condition] When the orientation of spindle positioning is completed, this signal is
1. When spindle positioning is performed or released, this signal is 0.
