12.COMPONENTS LIST B-63494EN/02
- 212 -
12.1 HARDWARE COMPONENTS
12.1.1 Hardware Components for Series
16i/18i/21i/160i/180i/210i/160is/180is/210is-MODEL A
No. Description
Specification number
Of primary component
Specification number
of secondary component
Remarks
1 Main board
A20B-8100-0130 A20B-8100-013X
A20B-8100-054X
A16B-3200-032X
2 CPU card A20B-3300-0170 A20B-3300-0050
A20B-3300-0260
A20B-3300-0070
3 Servo card A17B-3300-0200
A20B-3300-0244
A20B-3300-012X
A20B-3300-024X
A17B-3300-020X
4 DRAM MODULE A20B-3900-0131 A20B-3900-003X
A20B-3900-013X
A20B-3900-004X
5 SRAM MODULE A20B-3900-0060 A20B-3900-005X
A20B-3900-002X
A20B-3900-006X
6 FROM MODULE A20B-3900-0011 A20B-3900-001X A20B-3900-007X
12.1.2 Hardware Components for Series
16i/18i/21i/160i/180i/210i/160is/180is/210is-MODEL B
No. Description
Specification number
Of primary component
Specification number
of secondary component
Remarks
1 Main board A20B-8100-0660 A20B-8100-066X
A20B-8100-079X
A16B-3200-042X
2 CPU card A20B-3300-0311 A20B-3300-031X A20B-3300-029X
3 Servo card A20B-3300-0244
A17B-3300-0500
A20B-3300-024X A20B-3300-039X
4 FROM/SRAM MODULE A20B-3900-0160 A20B-3900-016X
A20B-3900-018X
5 Power supply module A20B-8100-0720 A20B-8100-0851
6 Sub CPU board A20B-8002-0190 A16B-2203-0751
7 Loader control board A20B-8100-0830 A16B-2203-0741
