Dual Check Safety Operators manual Page 222

Operators manual
12.COMPONENTS LIST B-63494EN/02
- 216 -
No. Description Module Name Specification number Remarks
5 Servo Amplifier Module
SVM1-180HV
i
A06B-6124-H106
(1 axis type, 400V input)
SVM1-360HV
i
A06B-6124-H109
6 Servo Amplifier Module
SVM1-4
i
A06B-6130-H001
(
βi series, 200V input) SVM1-20i
A06B-6130-H002
SVM1-40
i
A06B-6130-H003
SVM1-80
i
A06B-6130-H004
7 Servo Amplifier Module
SVM1-20HV
i
A06B-6131-H002
(
βHVi series, 400V input) SVM1-40HVi
A06B-6131-H003
8 Servo Amplifier Module SVM2-12/12 A06B-6096-H201
(2 axes type, 200V input) SVM2-12/20 A06B-6096-H202
SVM2-20/20 A06B-6096-H203
SVM2-12/40 A06B-6096-H204
SVM2-20/40 A06B-6096-H205
SVM2-40/40 A06B-6096-H206
SVM2-40/80 A06B-6096-H207
SVM2-80/80 A06B-6096-H208
SVM2-40L/40L A06B-6096-H209
SVM2-4/4
i
A06B-6114-H201
SVM2-20/20
i
A06B-6114-H205
SVM2-20/40
i
A06B-6114-H206
SVM2-40/40
i
A06B-6114-H207
SVM2-40/80
i
A06B-6114-H208
SVM2-80/80
i
A06B-6114-H209
SVM2-80/160
i
A06B-6114-H210
SVM2-160/160
i
A06B-6114-H211
9 Servo Amplifier Module
SVM2-10/10HV
i
A06B-6124-H202
(2 axes type, 400V input)
SVM2-20/20HV
i
A06B-6124-H205
SVM2-20/40HV
i
A06B-6124-H206
SVM2-40/40HV
i
A06B-6124-H207
SVM2-40/80HV
i
A06B-6124-H208
SVM2-80/80HV
i
A06B-6124-H209
10 Servo Amplifier Module SVM3-12/12/12 A06B-6096-H301
(3 axes type, 200V input) SVM3-12/12/20 A06B-6096-H302
10 Servo Amplifier Module SVM3-12/20/20 A06B-6096-H303
(3 axes type, 200V input) SVM3-20/20/20 A06B-6096-H304
SVM3-12/12/40 A06B-6096-H305
SVM3-12/20/40 A06B-6096-H306
SVM3-20/20/40 A06B-6096-H307
SVM3-4/4/4
i
A06B-6114-H301
SVM3-20/20/20
i
A06B-6114-H303
SVM3-20/20/40
i
A06B-6114-H304
11 Spindle Amplifier Module SPM-2.2-1 A06B-6102-H202#H520
(SPM HRV Type I, 200V input) SPM-5.5-1 A06B-6102-H206#H520
SPM-11-1 A06B-6102-H211#H520
SPM-15-1 A06B-6102-H215#H520
SPM-22-1 A06B-6102-H222#H520
SPM-26-1 A06B-6102-H226#H520
SPM-30-1 A06B-6102-H230#H520
SPM-45-1 A06B-6102-H245#H520
SPM-55-1 A06B-6102-H255#H520
12 Spindle Amplifier Module SPM-2.2-4 A06B-6102-H102#H520
(SPM HRV Type IV, 200V input) SPM-5.5-4 A06B-6102-H106#H520
