Dual Check Safety Operators manual Page 204

Operators manual
11.APPLYCATION OF OTHER FUNCTIONS B-63494EN/02
- 198 -
CAUTION
Set this parameter even when the semi-fixed angle
spindle positioning command is not executed.
Otherwise, the M codes from M00 to M05 do not
function normally.
4963 Basic rotation angle of spindle positioning
[Data type] Word
[Unit of data] deg
[Valid data range] 1 to 60
Set the basic rotation angle of the semi-fixed angle spindle positioning
command.
4964 Number of M codes for specifying a spindle positioning angle
[Data type] Byte
[Unit of data] Integer
[Valid data range] 0, 1 to 255
Set the number of M codes of the semi-fixed angle spindle positioning
command.
CAUTION
1 Make sure that the M code used for the semi-fixed
angle spindle positioning command does not
duplicate any other M codes.
2 This parameter is valid when bit 6 (ESI) of
parameter No. 4950 is 1.
3 When the setting of this parameter is 0, a setting of
6 is assumed.
