Dual Check Safety Operators manual Page 125

Operators manual
B-63494EN/02 6.PARAMETERS
- 119 -
CAUTION
1 When 0 is set, the safety position switch function of
the corresponding number is not used. (The safe
position switch signal of the corresponding number
is not output.)
2 If an axis for which Dual Check Safety is disabled
by setting bit 6 of parameter No. 1904 to 1 is
specified, the safe position switch signal of the
corresponding number is not output.
3 With each tool post other than tool post 2 in 1-CPU
2-path control and tool post 3 in 2-CPU 3-path
control, the 9th to 32nd safe position switches are
enabled only when an FSSB I/O module
(extension) is used. When no FSSB I/O module
(extension) is used, set 0 in parameter No. 13888
through No. 13911. If a setting is made to use the
9th through 32nd safe position switches when no
FSSB I/O module (extension) is used, servo alarm
No. 493 is issued at power-on time.
With tool post 2 in 1-CPU 2-path control or tool
post 3 in 2-CPU 3-path control, the safe position
switches are enabled only when an extension
module is used for the FSSB I/O module connected
to tool post 1 (1-CPU 2-path control) or tool post 3
(2-CPU 3-path control). When no FSSB I/O module
(extension) is used, set 0 in parameter No. 13880
to No. 13911. If a setting is made to use the safe
position switches when no FSSB I/O module
(extension) is used, servo alarm No. 493 is issued
at power-on time.
4 Parameter No. 13880 through No. 13911 are safety
parameters, so that these parameters are
protected using the key and code of Dual Check
Safety. To modify a parameter, set a code for
safety parameters as the key for safety parameters
(parameter No. 3226).
5 After safety position switch parameters No.13880
to No.13911 have been set, the power must be
turned off then back on for the setting to become
effective
