Dual Check Safety Operators manual Page 124

Operators manual
6.PARAMETERS B-63494EN/02
- 118 -
CAUTION
1 This parameter is a safety parameter, so that the
parameter is protected using the key and code of
Dual Check Safety. To modify the parameter, set a
code for safety parameters as the key for safety
parameters (parameter No. 3226).
2 When 0 is set in this parameter, the specification of
0 ms is assumed if bit 0 (CIO) of parameter No.
13800 (CIO) is set to 0, or the specification of 300
ms is assumed if bit 0 (CIO) of parameter No.
13800 (CIO) is set to 1.
3 When a value greater than 3000 (ms) is set in this
parameter, the specification of 3000 (ms) is
assumed.
13880 Axis corresponding to the 1st safe position switch
13881 Axis corresponding to the 2nd safe position switch
…
13911 Axis corresponding to the 32nd safe position switch
[Data type] Byte
[Valid data range] 1, 2, 3, …, Number of controlled axes
These parameters specify the control-axes numbers corresponding to
the 1st thorough 32nd safe position switch functions. If the machine
coordinate on the corresponding axis is within the parameter-set range,
the corresponding safe position switch signal is output via the PMC
and via the FSSB.
