1942 Safety speed for each axis
13821 Safety speed 1 for each axis
13822 Safety speed 2 for each axis
13823 Safety speed 3 for each axis
13824 Safety speed 4 for each axis
[Data type] 2-word axis
[Unit of data]
[Valid data range]
Valid data range
Parameter
TR2x
(No.13802#1)
Increment
system
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 0 to 240000 0 to 100000
Inch machine 0.1 inch/min 0 to 96000 0 to 48000
0
Rotation axis 1 deg/min 0 to 240000 0 to 100000
1 Not applicable 1 min
-1
0 to 32767
Set a safety speed for each axis.
The CNC and monitor always check the velocity command of each
axis in the dual check safety function. If the safety speed is exceeded
on one axis at least, the guard unlock signal (*LGD) is brought to 0, to
disable guard unlocking. The state in which the safety speed is not
exceeded on any axis is one condition for setting the guard unlock
signal (*LGD) to 1 (to enable guard unlocking).
If the safety speed is exceeded in safety signal mode C (state in which
a guard open request is input and the guard is open), a servo alarm
No.476 or No.494 is issued for the corresponding axis.
Up to four safety speeds can be set. Which safety speeds to choose
depends on the safety speed/safety position selection signal (safety
input signal). For details, see Section 5.2, "SIGNALS."
Safety speed 1 assumes the value of parameter No. 1942 if parameter
No. 1942 is not set to 0. Safety speed 1 assumes the value of
parameter No. 13821 if parameter No. 1942 is set to 0.
=
≠
=
0) 1942 No. (parameter 13821 No.Parameter
0) 1942 No. (parameter 1942 No.Parameter
1 speedSafety
By setting bit 1 (TR2x) of parameter No. 13802 to 1, a safety speed
can be monitored not by mm/min, inch/min, and deg/min but by motor
speed (min
-1
).
