Dual Check Safety Operators manual Page 154

Operators manual
8.MAINTENANCE B-63494EN/02
- 148 -
No. Meaning Description Servo axis
operation when
alarm is issued
786 SPINDLE-4 ILLEGAL
AXIS DATA
Same as alarm No. 756. (For the second spindle) Immediate stop
787 SPINDLE-4 SAFETY
SPEED OVER
Same as alarm No. 757. (For the second spindle) Immediate stop
7n16 SPN n :S-SPINDLE
ERROR (AL-16)
See the description of alarm 16 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n69 SPN n :S-SPINDLE
ERROR (AL-69)
See the description of alarm 69 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n70 SPN n :S-SPINDLE
ERROR (AL-69)
See the description of alarm 70 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n71 SPN n :S-SPINDLE
ERROR (AL-71)
See the description of alarm 71 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n72 SPN n :S-SPINDLE
ERROR (AL-72)
See the description of alarm 72 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n74 SPN n :S-SPINDLE
ERROR (AL-74)
See the description of alarm 74 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n76 SPN n :S-SPINDLE
ERROR (AL-76)
See the description of alarm 76 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n77 SPN n :S-SPINDLE
ERROR (AL-77)
See the description of alarm 77 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
7n78 SPN n :S-SPINDLE
ERROR (AL-78)
See the description of alarm 78 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9016 SPN n :S-SPINDLE
ERROR (AL-16)
See the description of alarm 16 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9069 SPN n :S-SPINDLE
ERROR (AL-69)
See the description of alarm 69 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9070 SPN n :S-SPINDLE
ERROR (AL-69)
See the description of alarm 70 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9071 SPN n :S-SPINDLE
ERROR (AL-71)
See the description of alarm 71 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9072 SPN n :S-SPINDLE
ERROR (AL-72)
See the description of alarm 72 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9074 SPN n :S-SPINDLE
ERROR (AL-74)
See the description of alarm 74 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9076 SPN n :S-SPINDLE
ERROR (AL-76)
See the description of alarm 76 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9077 SPN n :S-SPINDLE
ERROR (AL-77)
See the description of alarm 77 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
9078 SPN n :S-SPINDLE
ERROR (AL-78)
See the description of alarm 78 in Subsection 8.2.4. (For the n-th
spindle)
Immediate stop
