Dual Check Safety Operators manual Page 28

Operators manual
3.SAFETY FUNCTIONS B-63494EN/02
- 22 -
Controlled stop state
The power to the motor is not shut off.
The servo motor and the spindle motor are controlled to stop.
In the controlled stop state of either motor, the safety function is
active if the condition for enabling the safety function is satisfied (the
door is open). If a further abnormal event occurs, the motor is brought
into the safe stop state.
WARNING
1 The machine tool builder must design the machine
so that the machine is kept in the stop state if the
power to the servo motor driving circuit is shut off.
Example) Brake mechanism that would not drop
the vertical axis after the power is shut
off
2 If the power to the spindle motor driving circuit is
shut off, the spindle motor continues rotating at the
speed before the power-down and eventually
comes to a stop. A measure must be taken so that
this coasting does not affect safety.
