Dual Check Safety Operators manual Page 83

Operators manual
B-63494EN/02 5.I/O SIGNALS
- 77 -
WARNING
When using the safety brake output signals, be
sure to set the VRDY OFF alarm ignore signals for
all axes (IGNVRY, G066#0) and the VRDY OFF
alarm ignore signal (IGVRYx, G192) for each axis
to 0.
CAUTION
Be sure to inspect the brake periodically.
Programmable safe-related input signal
SDI00 to SDI15 <G334, G335>, <DI+002, DI+003>
[Classification] Input signal
[Function] This function is used only by the CNC and monitor to monitor input
signals with the dual check safety function.
[Operation] These signals can be freely used by the machine tool builder.
CAUTION
These signals cannot be used with path 2 in 1-CPU
2-path control and path 3 in 2-CPU 3-path control,
because those paths do not use an FSSB I/O
module.
Programmable safe-related output signal
SDO00 to SDO07 <G331> <DO+001>
[Classification] Input signal
[Function] This function is used only by the CNC and monitor to monitor output
signals with the dual check safety function.
[Operation] These signals can be freely used by the machine tool builder.
CAUTION
1 The term "output signal" means a signal not output
from the CNC but output as viewed from an
application created by the user. So, these signals
are G signals.
2 These signals cannot be used with path 2 in 1-CPU
2-path control and path 3 in 2-CPU 3-path control,
because those paths do not use an FSSB I/O
module.
