Dual Check Safety Operators manual Page 214

Operators manual
11.APPLYCATION OF OTHER FUNCTIONS B-63494EN/02
- 208 -
4031 Position coder method orientation stop position
[Data type] Word
[Unit of data] 1 pulse unit (360°/4096)
[Valid data range] 0 to 4096
Set the position coder method orientation stop position.
4038 Spindle orientation speed
[Data type] Word
[Unit of data] 1min
-1
[Valid data range] 0 to 32767
This parameter sets the orientation speed at the end of the spindle.
4042 Velocity loop proportional gain on orientation (HIGH gear)
4043 Velocity loop proportional gain on orientation (LOW gear)
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
This parameter sets the velocity loop proportional gain for spindle
orientation.
4050 Velocity loop integral gain on orientation (HIGH gear)
4051 Velocity loop integral gain on orientation (LOW gear)
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
This parameter sets the velocity loop integral gain for spindle
orientation.
4056 Gear ratio (HIGH gear)
4057 Gear ratio (MEDIUM HIGH gear)
4058 Gear ratio (MEDIUM LOW gear)
4059 Gear ratio (LOW gear)
[Data type] Word
[Unit of data] Motor speed per spindle rotation × 100
[Valid data range] 0 to 32767
These parameters set the gear ration between the spindle and spindle
motor.
