11.5.4 Parameters
#7 #6 #5 #4 #3 #2 #1 #0
1006 ROTx
[Data type] Bit axis
ROTx Controlled axis is:
0: Linear axis.
1: Rotation axis.
Set 1 for the Cs contour control axis.
1022 Setting of each axis in the basic coordinate system
[Data type] Byte axis
Specify whether each axis is one of the three basic axes (X, Y, Z) or
one of their parallel axes.
Set 0 for the Cs contour control axis.
1023 Number of the servo axis for each axis
[Data type] Byte axis
Set relationships between the individual axes and the servo axis
numbers.
Set one of -1, -2, -3, and -4 for the Cs contour control axis.
(Setting value)
-1 : Cs contour control axis by the first spindle
-2 : Cs contour control axis by the second spindle
-3 : Cs contour control axis by the third spindle
-4 : Cs contour control axis by the fourth spindle
CAUTION
1 When Cs contour control is performed by the
second to fourth spindles, bit 7 (CSS) of parameter
No. 3704 must be set to 1.
2 One spindle cannot be set as multiple Cs contour
control axes.
3 In multipath control, the spindle of another path
cannot be assigned.
#7 #6 #5 #4 #3 #2 #1 #0
3704 CSS
[Data type] Bit
CSS On the each spindle, Cs contour control is:
0: Not performed.
1: Performed.
Set 1 when Cs contour control is performed by the second to fourth
spindles.
