Dual Check Safety Operators manual Page 135

Operators manual
B-63494EN/02 6.PARAMETERS
- 129 -
6.4.5 PMC Axis Control (Speed Command)
If a speed command (axis control command 10h) is specified in PMC
axis control, the machine position is lost. So, the following parameters
need to be set so that the machine position is not monitored in dual
mode:
• Bit 0 (NP2x) of parameter No. 13802 = 1 (setting for not
monitoring position in dual mode)
• Bit 1 (TR2x) of parameter No. 13802 = 1 (setting for monitoring
speed in dual mode by motor speed)
At this time, the increment system for the safety speed
parameters changes. See the settings of parameter No. 1942 and
No. 13821 through No. 13824 in Section 6.2.
CAUTION
When a speed command is specified in PMC axis
control by position specification (when bit 4 (EJG)
of parameter No. 8005 = 1), the machine position is
not lost. So, bit 0 (NP2x) and bit 1 (TR2x) of
parameter No. 13802 need not be set to 1.
