Dual Check Safety Operators manual Page 159

Operators manual
B-63494EN/02 9.DIAGNOSIS
- 153 -
9.2 DIAGNOSIS
#7 #6 #5 #4 #3 #2 #1 #0
Diagnosis No. 376 FMC FGL FGD
The current states of safety signals input via the FSSB are displayed.
FGD The state of the guard state signal (SGD2) is displayed.
FGL The state of the guard lock state signal (GDL2) is displayed.
FMC The state of the MCC contact state signal (*SMC2) is displayed.
#7 #6 #5 #4 #3 #2 #1 #0
Diagnosis No. 377 PMC PGL PGD PRQ PTS
The current states of safety signals input via the PMC are displayed.
PTS The state of the test mode signal (OPT) is displayed.
PRQ The state of the guard open request signal (ORQ) is displayed.
PGD The state of the guard state signal (SGD1) is displayed.
PGL The state of the guard lock state signal (GDL1) is displayed.
PMC The state of the MCC contact state signal (*SMC1) is displayed.
#7 #6 #5 #4 #3 #2 #1 #0
Diagnosis No. 378 ESP TST MDD MDC MDB MDA
The current safety signal mode is displayed.
MDA Safety signal mode A
MDB Safety signal mode B
MDC Safety signal mode C
MDD Safety signal mode D
TST MCC off test mode
ESP Emergency stop mode
Diagnosis No. 379 Test number of MCC off test
The test number of the MCC off test is displayed.
Zero is displayed if the system is not in the MCC off test mode.
After the MCC off test mode is selected by the input of the test mode
signal (OPT), the test number increases by 1 from 0 as the MCC off
test proceeds. When the MCC off test is completed, the test number is
128. When the test mode signal (OPT) is set to 0 to clear the MCC off
test mode, the test number is cleared to 0.
