Dual Check Safety Operators manual Page 37

Operators manual
B-63494EN/02 3.SAFETY FUNCTIONS
- 31 -
IMPORTANT
3 Before inputting the guard open request signal,
reduce each axial speed and spindle speed to a
safety speed range or below. If a speed exceeds
the limit, the guard open request signal is not
accepted (the door is not unlocked). If the door is
forced open, the power to the driving circuit is shut
off (safe stop state).
WARNING
The safety speed monitoring function monitors
whether the traveling speed exceeds a specified
limit. The function cannot monitor the stop state
(zero speed).
If an error causes a movement on the feed axis at
a speed lower than the safety speed range while
the protective door is open, for instance, the
function cannot detect this state. The machine
must be designed so that this state does not affect
the safety of the machine system.
