Dual Check Safety Operators manual Page 131

Operators manual
B-63494EN/02 6.PARAMETERS
- 125 -
1936 Unit number of the 1st FSSB I/O unit
1937 Unit number of the 2nd FSSB I/O unit
CAUTION
1 When these parameters have been set, the power
must be turned off before operation is continued.
2 These parameters are shared for the connector
numbers of the first and second separate detector
interface units.
[Data type] Byte axis
[Valid data range] 0, 1
When using the first FSSB I/O unit and the second FSSB I/O unit, set
the following values in parameter No. 1936 and No. 1937,
respectively:
• Axis with No. 1023 = 1: 0 (setting for using the FSSB I/O basic
unit)
(For tool post 2 in 2-CPU 2-path control and 2-CPU 3-path
control, the same setting needs to be made for an axis with No.
1023 = 9.)
• Axis with No. 1023 = 2: 1 (setting for using the FSSB I/O
extension unit)
(For tool post 2 in 2-CPU 2-path control and 2-CPU 3-path
control, the same setting needs to be made for an axis with No.
1023 = 10.)
• Other axes: 0
