6.PARAMETERS B-63494EN/02
- 126 -
6.4 FUNCTIONS THAT REQUIRE SPECIAL PARAMETER
SETTINGS
6.4.1 Tandem Control
To use tandem control, set the following parameters.
• Master axis
No special parameter settings are required.
• Slave axis
No.1904#6(DCN)=1
No.2078=0
No.2079=0
6.4.2 Simple Electronic Gear Box and Electronic Gear Box 2-pair
To use a simple electronic gear box or electronic gear box 2-pair, set
the following parameters.
• Workpiece axis
No special parameter settings are required.
• Tool axis (EGB axis)
No.1904#6(DCN)=1
6.4.3 Multi-path Control
To use multi-path control, set the following parameters.
• 2-CPU 2-path control (without axis change between paths)
No special parameter settings are required.
• 2-CPU 2-path control (with axis change between paths)
No.1023
The first servo axis cannot be changed between paths.
Accordingly, set parameter No.1023 to 1 for the axis of tool
post 1 and to 9 for the axis of tool post 2.
When an FSSB I/O extension unit is used, the second servo
axis cannot be changed between paths. Accordingly, set
parameter No. 1023 to 2 for the axis of tool post 1, and set
parameter No. 1023 to 10 for the axis of tool post 2.
No.1945, No.1947, No.1948, No.1950
Set identical values for the two tool posts.
• 1-CPU 2-path control
No.1023
Set parameter No.1023 to 1 for the axis of tool post 1.
When an FSSB I/O extension unit is used, set parameter No.
1023 to 2 for the axis of tool post 1.
No.1945, No.1947, No.1948, No.1950
Set identical values for the two tool posts.
