Dual Check Safety Operators manual Page 189

Operators manual
B-63494EN/02 11.APPLYCATION OF OTHER FUNCTIONS
- 183 -
11.2.3 Signals
11.2.3.1 Details on signals
Manual handle feed maximum feedrate change signal
HNDLF <G023#3>
[Classification] Input signal
[Function] This signal switches to or from the maximum manual handle feedrate.
[Operation] When this signal is 1, the speed set in parameter No. 1434 is assumed
as the manual handle feed maximum speed. When external
deceleration setting 2 or 3 is used, the speed set in parameter No. 1442
or 1445 can also be enabled.
External deceleration signals
*+ED1 to *+ED8 <G118>
*-ED1 to *-ED8 <G120>
*+ED21 to *+ED28 <G101>
*-ED21 to *-ED28 <G103>
*+ED31 to *+ED38 <G107>
*-ED31 to *-ED38 <G109>
[Classification] Input signal
[Function] This signal selects which external deceleration to apply for each
direction of the control axes with the external deceleration function. In
a signal name, "+" and "-" indicate a direction, the second number
from the end indicates the target setting, and the last number indicates
the control axis number.
*x
EDyz
z
1: External deceleration for 1st axis
2: External deceleration for 2nd axis
3: External deceleration for 3rd axis
: :
: :
y
1: External deceleration setting 1
2: External deceleration setting 2
3: External deceleration setting 3
x
+: Feed in the positive direction
-: Feed in the negative direction
[Operation] When this signal is 0, the feedrate of the corresponding axis in the
corresponding direction is decreased to the corresponding speed.
In manual handle feed, however, when the external deceleration signal
in either the positive direction or the negative direction is 0, external
decelerations in both directions are enabled (it is impossible to select
one direction). The external deceleration signal (G118, G120) of
external deceleration setting 1 has no effect on the maximum speed of
manual handle feed.
