11.5.3 Signals
11.5.3.1 Details on signals
Cs contour control change signal
CON <G027#7>
[Classification] Input signal
[Function] This signal specifies for the first spindle to switch between the spindle
rotation control mode and the Cs contour control mode in the Cs
contour control function.
When this signal is set to 1, the spindle is switched from the spindle
rotation mode to the Cs contour control mode. When this signal is set
to 1 while the spindle is rotating, the spindle stops immediately and
then enters the Cs contour control mode.
When this signal is set to 0, the spindle is switched from the Cs
contour control mode to the spindle rotation mode.
CAUTION
This signal is enabled only when bit 7 (CSS) of
parameter No. 3704 is 0.
When bit 7 (CSS) of parameter No. 3704 is 1
(when Cs-axis contour control by the individual
spindles is used), use the Cs contour change
signals (G274#0 (CONS1) to #3 (CONS4)) of the
individual spindles.
Cs contour control change completion signal
FSCSL <F044#1>
[Classification] Output signal
[Function] This signal indicates that the Cs contour control mode is entered.
[Output condition] In the spindle rotation control mode, this signal is 0.
In the Cs contour control mode, this signal is 1.
CAUTION
This signal is enabled only when bit 7 (CSS) of
parameter No. 3704 is 0.
When bit 7 (CSS) of parameter No. 3704 is 1
(when Cs-axis contour control by the individual
spindles is used), use the Cs contour change
completion signals (F274#0(FCCS1) to
#3(FCCS4)) of the individual spindles.
