Dual Check Safety Operators manual Page 215

Operators manual
B-63494EN/02 11.APPLYCATION OF OTHER FUNCTIONS
- 209 -
4060 Position gain on orientation (HIGH gear)
4061 Position gain on orientation (MEDIUM HIGH gear)
4062 Position gain on orientation (MEDIUM LOW gear)
4063 Position gain on orientation (LOW gear)
[Data type] Word
[Unit of data] 0.01 sec
-1
[Valid data range] 0 to 32767
These parameters set the position gain for orientation.
4064 Modification rate of position gain on orientation completion
[Data type] Word
[Unit of data] 1%
[Valid data range] 0 to 1000
This data is used to set the modification rate of position gain on
spindle orientation completion.
4075 Orientation completion signal detection level (limits of in-position)
[Data type] Word
[Unit of data] 1 pulse unit (360°/4096)
[Valid data range] 0 to 100
This data is used to set the detecting level of orientation completion
signal (ORARA).
When the spindle position is located within the setting data on
orientation completion, the bit of orientation completion signal
(ORARA) in the spindle control signals is set to "1".
4076 Motor speed limit ratio on orientation
[Data type] Word
[Unit of data] 1%
[Valid data range] 0 to 100
This data is used to set motor speed limit ratio on orientation.
4077 Orientation stop position shift value
[Data type] Word
[Unit of data] 1 pulse unit (360°/4096)
[Valid data range] -4095 to 4095
In the position coder method orientation, set this data to shift stop
position.
4084 Motor voltage setting on orientation
[Data type] Word
[Unit of data] 1%
[Valid data range] 0 to 100
This parameter sets the motor voltage for orientation.
