Dual Check Safety Operators manual Page 126

Operators manual
6.PARAMETERS B-63494EN/02
- 120 -
13920 Maximum operation range of the 1st safe position switch
13921 Maximum operation range of the 2nd safe position switch
…
13951 Maximum operation range of the 32nd safe position switch
[Data type] 2-word
[Unit of data]
Increment system IS-A IS-B IS-C Unit
Millimeter machine 0.01 0.001 0.0001 mm
Inch machine 0.001 0.0001 0.00001 inch
Rotation axis 0.01 0.001 0.0001 deg
[Valid data range] -99999999 to 99999999
These parameters set the maximum operation range of the 1st through
32nd safe position switches.
CAUTION
1 The operation range of a safe position switch signal
is checked in terms of the detection unit. So, a
calculation error can result.
2 When the machine position is on the boundary of
the specified ranges (machine position = parameter
setting value), it is considered within the specified
ranges.
3 When the setting of operation range is “maximum
operation range < minimum operation range”, the
safe position switch is not output.
4 Parameter No. 13920 through No. 13951 are safety
parameters, so that these parameters are
protected using the key and code of Dual Check
Safety. To modify a parameter, set a code for
safety parameters as the key for safety parameters
(parameter No. 3226).
5 If parameter No.13920 to No.13951 are changed,
please turn the power of the machine off once.
