5. MAINTENANCE
117
The FANUC LASER C series contains consumables that must be
replaced periodically. Table 5.2 (a), (b) lists such consumables and the
related periodic maintenance work. Perform periodic maintenance as
well as daily inspection described in Section 5.1 by using the listed
periods as guidelines. Also use the reading of the hour meter, which
roughly indicates how long the laser has been running. Note, however,
that the replacement and maintenance intervals are not guaranteed values
but standard values based on field records.
Table 5.2 (a) Periodic maintenance items and periods
Interval of maintenance (Operation hour)
Item
C1500B
C2000B
C2000C
C3000C
C3000D
1 Output mirror cleaning
2 Rear mirror cleaning
3000 to 4000h 1500 to 2000h 800 to 1200h
3 Folding mirror cleaning 3000 to 4000h
4 0–shift mirror cleaning 1000h or processing quality go wrong
5 Output mirror change 4000h or inferior beam mode
6 Rear mirror change 4000h or inferior beam mode
7 Folding mirror change 4000h or inferior beam mode
8 0–shift mirror change 4000h or inferior beam mode
9 Exhaust pump oil change 1500h or low exhaust ability
10 Exhaust pump filter change 3000h or low exhaust ability
11 Exhaust pump overhaul 10000h or low exhaust ability
12 Turbo blower oil change 1500h or inferior turbo blower oil
13 Turbo blower overhaul 12000h or low turbo blower ability
14 Pressure control filter change 12000h or pressure alarm occurs
15 Discharge tube O–ring change 6000h or intra–cavity leakage occurs
16 Cooling water 1500h or inferior water quality
17 Water tubing cleaning 3000h or water flow is blocked
18 Beam absorber 15000h or over heat alarm occurs
19 Nylon tube 15000h
20 Cable 15000h
