LASER C SERIES Maintenance manual Page 417

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
417
15223 LVCMD
LVCMD0250
LVCMD Bias command in oscillator preparation completion state
After the start of discharge is confirmed, the bias voltage of discharge
current command is replaced by this parameter. This replacement is
performed during a rise in the gas pressure (time set with parameter No.
15249: FS16–L, FS16i–L, or 20 sec: FS0–L).
[Setting range] 0 to 3000
[Unit] mV
[Standard setting] Refer to the parameter data sheet delivered with the machine.
15224 VD
VD Modulation voltage
This parameter specifies a voltage value by which the normal bias
command value is decreased with the base modulation function.
[Setting range] 0 to 32767
[Unit] mV
15225 TD
TD Modulation time
This parameter specifies a time for which the bias command value is
decreased with the base modulation function.
[Setting range] 0 to 32767
[Unit] 10 msec
