LASER C SERIES Maintenance manual Page 91

Maintenance manual
B–70115EN/03
4. INSTALLATION
89
D Pressurization
CAUTION
The turbo blower is not designed to withstand
pressurization. So, whenever possible, do not perform a
leakage check by pressurizing the turbo blower. Even when
internal pressurization is inevitable, never apply a pressure
in excess of 0.08 MPa. Otherwise, components such as
connectors or the oil gauge may be damaged. To minimize
the risk of connector damage, connect all cables to the turbo
blower when applying pressure.
1) Turn on the power to the oscillator, then open the valve of the
gas cylinder.
2) Set the secondary pressure of the gas cylinder regulator to 0.05
MPa.
3) To increase the internal pressure of the oscillator to a level
exceeding atmospheric pressure, turn the trimmer of the
atmospheric pressure sensor (installed in the pressure sensor
section) clockwise by half a division.
4) Set the RUN key on the oscillator to ON, then immediately
return the RUN key to OFF.
5) Apply leakage check liquid to possible leak points. Bubbles
will be seen if there is a leak. Thus, any leak points can be
identified.
6) Upon the completion of the above processing, return the
trimmer rotated in step 3) to its original setting.
(7)Parameter check
Laser oscillator parameter data is attached to each oscillator. Machine
tool builders may prepare a parameter table including the laser
oscillator parameter data. If the attached parameter data sheets are
missing, contact your machine tool builder.
1) On the NC setting screen, enable parameter rewriting.
2) Check the parameters, and enter the same values as those given in
the parameter table.
3) On the NC setting screen, disable parameter rewriting, then press
the reset key.
