LASER C SERIES Maintenance manual Page 467

Maintenance manual
B–70115EN/03
G. REFIXING AND REPLACING
WATER TUBE
APPENDIX
467
1) (a) In case of brass fitting
Mount a new sleeve on the tube.
(b) In case of stainless steel fitting
If a sleeve is necessary, mount a new sleeve on the tube. If no
sleeve is necessary, insert the tube as is.
In mounting sleeve, refer to Fig. G.1 and follow the order shown
in the figure.
Here make sure not to introduce dust into sleeve and tube. If
contaminated, wipe with soft and clean cloth.
NOTE
Old nut can be used but only new sleeve can be used.
Otherwise there may occur water leakage.
2) Mount tube and fasten it.
In fixing, hold fitting base with wrench. Follow the procedures of Sec.
G.1 3), 4) in fixing.
G.2
REPLACING TUBE
