LASER C SERIES Maintenance manual Page 79

Maintenance manual
B–70115EN/03
4. INSTALLATION
77
(3) Check the units installed in the main unit cabinet.
D Check items
1) Check whether any printed circuit boards are loose or removed.
2) Check whether any cables are damaged (such as damaged
sheathing).
3) Check whether any connectors are loose or detached.
4) Check that the discharge tubes are neither cracked nor damaged.
5) Check that the turbo blowers, exhaust pump, and other units are
neither loose nor missing.
6) Check that the power supply units and matching boxes are
neither loose nor missing.
7) Check that the input unit is neither loose nor missing.
8) Check that the connection to the electrode (copper plate) of each
discharge tube is not loose.
9) Check that the water and gas pipes are not loose.
(4) Check all screw terminals in the units.
D Check items
1) Terminal block of the input unit
2) Power supply units and matching boxes
(5) Check the oil level in the turbo blowers and exhaust pump, and check
for oil contamination.
For details of how to supply and replace the oil, see Section 5.3.
(6) Connect the power and signal lines to the oscillator.
See Section 4.4.3 for details.
D Check items
1) Cable between the NC and oscillator
To connect this cable, apply the procedure described in the
“FANUC Series 0–L/16–L/16i–L Connection Manual.”
2) Oscillator power cable
3) Grounding cable (class–1)
4) Inter–unit connection between the oscillator and supplement
unit (C3000C)
(7) Check all printed circuit board settings.
D Check items
1) Setting pins on the oscillator IF PCB
See Section 6.5.5 for an explanation of the setting pins on the
IF PCB.
(8) Laser gas and cooling water pipes.
See Section 4.4.1 and Section 4.4.2 for details.
D Check items
1) Laser gas pipe type
Recommended gas pipe
Nylon tube AS1, manufactured by Junko Co. Ltd.
Polyprotube, manufactured by Imperial Co. Ltd.
2) Gas leakage from external piping
