1. Fanuc
  2. LASER C SERIES

LASER C SERIES Maintenance manual Page 483

Maintenance manual
TITLE
DRAW
.
No.
2
/
2
Pa
g
e
FANUC LTD
DESCRIPTIONDESIGNDATE
EDIT
B-70115EN/03-01
New re
g
istrationT.SATO01.06.1101
In FANUC LASER C series MAINTENANCE MANUAL B-70115EN/03, the interval of turbo
blower oil change
is corrected on page 112,113.
Table 5.2(a) Periodic maintenance items and periods (Page 112)
Interval of maintenance (Operation hour)
C1500B
C2000B
C2000C
C3000C
C3000D
12 Turbo blower oil change
True : 1000h or inferior turbo blower oil
False : 1500h or inferior turbo blower oil
Table 5.2(b) Periodic maintenance items and periods (Page 113)
Interval of maintenance (Operation hour)
C4000A C6000B
12 Turbo blower oil change
True : 1000h or inferior turbo blower oil
False : 1500h or inferior turbo blower oil
Previous page
Next page
